Ideal for legacy and modern surveillance applications, the SX-Series is equipped with analogue and digital connectivity as well as Composite output for video looping. Built to last and perform in 24/7 operations, it features AG Neovo’s Anti-Burn-in™ technology, preventing image ghosting and ensuring professionals view the present, not the past. Coupled with NeoV™ Optical Glass and metal casing, the display is shielded from incidental damage and impact to withstand the most demanding environments. Highly versatile and compatible, the SX-Series is the optimal display solution for seamless video surveillance transition.
Industry-leading Reliability
The SX-Series is specially designed to transcend the challenge of enduring 24/7 operations. AG Neovo’s Anti-Burn-inTM technology also prevents image ghosting while performing nonstop mission-critical operations. Its metal casing and NeoVTM Optical Glass not only protect the SX-Series from damage but also keep maintenance easy.
Optimised for Surveillance and Security
Built with cutting-edge super-resolution technology, the SX-Series can upscale images at a higher and more detailed resolution for better clearness. Besides, geared specifically for a surveillance control room, a user-friendly CCTV mode is pre-configured to maximise image clarity in the scenario of low light surveillance footage at night.
Highly Versatile and Compatible
The SX-Series supports multiple video input sources, from legacy video cameras to the latest HDMI and DisplayPort equipment. Its lockable Composite input and loop through Composite output make it easy to connect to other gear without the need for a splitter.
| Design |
|---|
| Certification |
CB, CE, FCC, WEEE, REACH, BSMI |
| LED indicators |
Yes |
| Tilt angle |
20° |
| Tilt angle range |
0 - 20° |
| Tilt adjustment |
Yes |
| Product colour |
Black |
| Mounting type |
Freestanding/Wall-mounted |
| Product type |
CCTV monitor |
| Display |
|---|
| Glass thickness |
3 mm |
| Anti-glare screen |
Yes |
| RGB colour space |
NTSC |
| NTSC coverage (typical) |
72% |
| Response time |
3 ms |
| Contrast ratio (typical) |
20000000:1 |
| Vertical scan range |
50 - 75 Hz |
| Horizontal scan range |
24 - 83 kHz |
| Pixel pitch |
0.294 x 0.294 mm |
| Display number of colours |
16.78 million colours |
| Viewing angle, vertical |
160° |
| Viewing angle, horizontal |
170° |
| Display aspect ratio |
4:3 |
| Backlight type |
LED |
| Display brightness |
250 cd/m² |
| Panel type |
TN |
| Display type |
LCD |
| Display resolution |
1280 x 1024 pixels |
| Display diagonal |
48.3 cm (19") |
| Performance |
|---|
| Cable lock slot |
Yes |
| Cable lock slot type |
Kensington |
| VESA mounting |
Yes |
| Panel mounting interface |
75 x 75,100 x 100 mm |
| Speaker power |
2 W |
| Number of built-in speakers |
2 |
| Built-in speaker(s) |
Yes |
| Ports & interfaces |
|---|
| DC-in jack |
Yes |
| 3.5 mm (1/8-inch) in |
Yes |
| Composite video out |
1 |
| Composite video in |
1 |
| USB 2.0 ports quantity |
1 |
| USB port |
Yes |
| VGA (D-Sub) ports quantity |
1 |
| DVI-D ports quantity |
1 |
| HDMI version |
1.4 |
| HDMI ports quantity |
1 |
| Power |
|---|
| AC adapter output current |
1.75 A |
| AC adapter output voltage |
12 V |
| Power consumption (off) |
0.3 W |
| Power consumption (standby) |
0.5 W |
| Power consumption (typical) |
16 W |
| Power supply type |
External |
| Power source type |
DC |
| Operational conditions |
|---|
| Storage relative humidity (H-H) |
5 - 95% |
| Operating relative humidity (H-H) |
10 - 90% |
| Storage temperature (T-T) |
-20 - 60 °C |
| Operating temperature (T-T) |
0 - 40 °C |
| Technical details |
|---|
| Compliance certificates |
CE, REACH, RoHS, WEEE |
| Weight & dimensions |
|---|
| Package weight |
93 kg |
| Package height |
526 mm |
| Package depth |
225 mm |
| Package width |
552 mm |
| Package type |
Box |
| Weight (with stand) |
6.9 kg |
| Height (with stand) |
420.2 mm |
| Depth (with stand) |
175 mm |
| Width (with stand) |
445.4 mm |
| Width |
445.4 mm |
| Depth |
64.5 mm |
| Height |
383.9 mm |
| Weight |
6.1 kg |
| Packaging content |
|---|
| Quantity |
1 |
| Cables included |
AC, Audio, VGA |
| AC adapter included |
Yes |
