Vigor C410ax 4G Mobile Broadband Wireless AX3000 Ethernet Router with integrated sim slot, VPN and Firewall
| WAN connection |
|---|
| 3G/4G USB modem compatibility |
No |
| SIM card slot |
Yes |
| DSL WAN |
No |
| Ethernet WAN |
Yes |
| Wireless LAN features |
|---|
| Wi-Fi standards |
Wi-Fi 6 (802.11ax) |
| WLAN data transfer rate (max) |
3000 Mbit/s |
| Top Wi-Fi standard |
Wi-Fi 6 (802.11ax) |
| Wi-Fi band |
Dual-band (2.4 GHz / 5 GHz) |
| Network |
|---|
| VPN tunnels quantity |
4 |
| VPN server |
Yes |
| Wireless Distribution System (WDS) bridge |
Yes |
| Static route |
Yes |
| SSID-based VLAN assignment |
Yes |
| Policy-based routing |
Yes |
| Dynamic DNS (DDNS) |
Yes |
| Port forwarding |
Yes |
| Ethernet LAN interface type |
Gigabit Ethernet |
| Ethernet LAN |
Yes |
| Mobile network |
|---|
| SIM card type |
NanoSIM |
| Dual SIM support |
Yes |
| Mobile network generation |
4G |
| Ports & interfaces |
|---|
| Ethernet LAN (RJ-45) ports |
5 |
| Management features |
|---|
| MU-MIMO technology |
Yes |
| MIMO |
Yes |
| WPS push button |
Yes |
| Intelligent Mesh technology |
Yes |
| Reset button |
Yes |
| Quality of Service (QoS) support |
Yes |
| Bandwidth control |
Yes |
| Web-based management |
Yes |
| Security |
|---|
| Network address translation (NAT) |
Yes |
| System event log |
Yes |
| URL filtering |
Yes |
| IP address filtering |
Yes |
| MAC address filtering |
Yes |
| Filtering |
Yes |
| DoS attack prevention |
Yes |
| Parental control |
Yes |
| Stateful Packet Inspection (SPI) |
Yes |
| Access Control List (ACL) |
Yes |
| Firewall |
Yes |
| Protocols |
|---|
| Routing protocols |
BGP, OSPF, OSPFv2, OSPFv3, RIP, RIP-1, RIP-2 |
| Universal Plug and Play (UPnP) |
Yes |
| DHCP server |
Yes |
| DHCP client |
Yes |
| Design |
|---|
| On/off switch |
Yes |
| LED indicators |
Activity, LAN, LTE, WAN, WLAN |
| Indication light |
Yes |
| Wall mountable |
Yes |
| Housing material |
Plastic |
| Packaging content |
|---|
| Quick start guide |
Yes |
| Antenna included |
Yes |
| AC adapter included |
Yes |
| Cables included |
LAN (RJ-45) |
| Certificates |
|---|
| PSTI certified |
Yes |
| Compliance certificates |
CE, UKCA |
| Antenna |
|---|
| Detachable antenna(s) |
Yes |
| Antenna design |
External |
| Features |
|---|
| Firmware upgradeable |
Yes |
| Languages support |
English |
| Operating system installed |
DrayOS |
| Power |
|---|
| External power adapter |
Yes |
| Power consumption (typical) |
16.2 W |
| Power source type |
AC |
| Operational conditions |
|---|
| Operating temperature (T-T) |
0 - 45 °C |
| Storage temperature (T-T) |
-25 - 70 °C |
| Operating relative humidity (H-H) |
10 - 90% |
| Weight & dimensions |
|---|
| Width |
207 mm |
| Depth |
131 mm |
| Height |
42 mm |
| Weight |
840 g |
| Logistics data |
|---|
| Country of origin |
Taiwan |
| Warranty period |
2 year(s) |
