Your Best Work, Done Faster Than Ever
Performance That Keeps Up With Your Creativity- Powerful AMD Ryzen™ HX processor for demanding workloads
- Colour-calibrated display for perfect detail in every creative project
- Dedicated NVIDIA RTX® graphics included for creative professionals
| Design |
|---|
| Housing material |
Aluminium |
| Form factor |
Clamshell |
| Colour name |
Luna grey |
| Product colour |
Grey |
| Product type |
Laptop |
| Display |
|---|
| High Dynamic Range (HDR) technology |
DisplayHDR 400 |
| High Dynamic Range (HDR) supported |
Yes |
| Contrast ratio (typical) |
1200:1 |
| Maximum refresh rate |
240 Hz |
| RGB colour space |
DCI-P3 |
| Colour gamut |
100% |
| Display brightness |
500 cd/m² |
| Anti-glare screen |
Yes |
| LED backlight |
Yes |
| Native aspect ratio |
16:10 |
| Panel type |
IPS |
| HD type |
WQXGA |
| Touchscreen |
No |
| Display resolution |
2560 x 1600 pixels |
| Display diagonal |
40.6 cm (16") |
| Processor |
|---|
| Processor base power |
55 W |
| L2 cache |
16 MB |
| L3 cache |
64 MB |
| Processor frequency |
2.5 GHz |
| Processor boost frequency |
5.4 GHz |
| Processor threads |
32 |
| Processor cores |
16 |
| Processor model |
8945HX |
| Processor generation |
AMD Ryzen 8000 Series |
| Processor family |
AMD Ryzen™ 9 |
| Processor manufacturer |
AMD |
| Memory |
|---|
| Memory channels |
Dual-channel |
| Maximum internal memory |
64 GB |
| Memory slots |
2x SO-DIMM |
| Memory layout (slots x size) |
2 x 16 GB |
| Memory clock speed |
5200 MHz |
| Memory form factor |
SO-DIMM |
| Internal memory type |
DDR5-SDRAM |
| Internal memory |
32 GB |
| Storage |
|---|
| Compatible memory cards |
SD |
| Card reader integrated |
Yes |
| Optical drive type |
No |
| SSD form factor |
M.2 |
| M.2 SSD size |
2242 (22 x 42 mm) |
| SSD interface |
PCI Express 4.0 |
| NVMe |
Yes |
| SSD capacity |
1 TB |
| Number of SSDs installed |
1 |
| Total SSDs capacity |
1 TB |
| Storage media |
SSD |
| Total storage capacity |
1 TB |
| Graphics |
|---|
| NVIDIA G-SYNC |
Yes |
| On-board graphics card model |
AMD Radeon 610M |
| On-board graphics card family |
AMD Radeon |
| On-board GPU manufacturer |
AMD |
| Discrete graphics memory type |
GDDR7 |
| Discrete graphics card memory |
8 GB |
| Discrete graphics card model |
NVIDIA GeForce RTX 5060 |
| Discrete GPU manufacturer |
NVIDIA |
| Discrete graphics card |
Yes |
| On-board graphics card |
Yes |
| Audio |
|---|
| Built-in microphone |
Yes |
| Number of microphones |
2 |
| Speaker power |
2 W |
| Number of built-in speakers |
2 |
| Audio chip |
Realtek ALC3287 |
| Camera |
|---|
| Privacy type |
Privacy shutter |
| Privacy camera |
Yes |
| Front camera resolution |
1280 x 720 pixels |
| Front camera HD type |
HD |
| Front camera |
Yes |
| Network |
|---|
| WWAN |
Not installed |
| Bluetooth version |
5.4 |
| Bluetooth |
Yes |
| Ethernet LAN |
No |
| Antenna type |
2x2 |
| Wi-Fi standards |
Wi-Fi 7 (802.11be) |
| Top Wi-Fi standard |
Wi-Fi 7 (802.11be) |
| Mobile network connection |
No |
| Ports & interfaces |
|---|
| USB Sleep-and-Charge ports |
1 |
| USB Sleep-and-Charge |
Yes |
| USB Type-C DisplayPort Alternate Mode |
Yes |
| Combo headphone/mic port |
Yes |
| HDMI version |
2.1 |
| HDMI ports quantity |
1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity |
2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity |
1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
2 |
| Performance |
|---|
| Motherboard chipset |
AMD SoC |
| Keyboard |
|---|
| Copilot key |
Yes |
| Spill-resistant keyboard |
Yes |
| Numeric keypad |
Yes |
| Keyboard backlit |
Yes |
| Keyboard language |
UK English |
| Keyboard layout |
QWERTY |
| Pointing device |
Touchpad |
| Software |
|---|
| Operating system architecture |
64-bit |
| Battery |
|---|
| Fast charging time (50%) |
30 min |
| Fast charging |
Yes |
| Battery life (max) |
4.11 h |
| Battery capacity |
85 Wh |
| Battery technology |
Lithium-Ion (Li-Ion) |
| Power |
|---|
| USB Power Delivery (USB PD) |
Yes |
| USB Type-C charging port |
Yes |
| AC adapter input voltage |
100 - 240 V |
| AC adapter frequency |
50/60 Hz |
| AC adapter power |
300 W |
| Security |
|---|
| Password protection type |
BIOS, Power on, Supervisor |
| Password protection |
Yes |
| Trusted Platform Module (TPM) |
Yes |
| Trusted Platform Module (TPM) version |
2.0 |
| Fingerprint reader |
No |
| Cable lock slot type |
Kensington |
| Cable lock slot |
Yes |
| Operational conditions |
|---|
| Maximum shipping altitude |
3048 m |
| Storage relative humidity (H-H) |
5 - 95% |
| Operating relative humidity (H-H) |
8 - 95% |
| Storage temperature (T-T) |
5 - 43 °C |
| Operating temperature (T-T) |
5 - 35 °C |
| Certificates |
|---|
| Certification |
ErP Lot 3Eyesafe Certified 2.0TÜV Rheinland Low Blue Light (Hardware Solution) |
| Compliance certificates |
RoHS |
| Sustainability |
|---|
| Sustainability certificates |
ENERGY STAR, EPEAT Gold |
| Weight & dimensions |
|---|
| Height |
19.3 mm |
| Depth |
256.2 mm |
| Width |
354.6 mm |
| Weight |
2.15 kg |
| General |
|---|
| Product family |
ThinkBook |
| Packaging content |
|---|
| AC adapter included |
Yes |
