Live Your Digital Life at Gigabit Speed
AC1200 Wireless Dual Band Gigabit Router
AC1200 Gigabit Speeds
Dual Band WiFi Delivers Fast Connections for All Devices
Complying with the powerful 802.11ac standard, MR30G delivers blazing-fast WiFi speeds up to 1.2 Gbps. Choose the 2.4 GHz band (300 Mbps) that transmits signals with better wall penetration for longer distance as you browse the internet, email a colleague, or share a link on social media. When you’re streaming HD videos, gaming, or other bandwidth-intensive tasks, choose the 5 GHz band (867 Mbps) which delivers higher speeds with less interference
High-Gain Antennas with Beamforming
Targeted Signals that Penetrate Walls
Four external 5 dBi high-gain antennas with well-designed internal structures greatly increase transmission performance, covering more rooms. Advanced Beamforming technology automatically locates wireless devices and forms targeted, highly efficient wireless connections, making your connections more stable.
Powerful Signal Amplifiers
Strong WiFi Signals Throughout Your Home
MR30G unleashes the full potential of your network by strengthening signal transmissions with power amplifiers, and accelerating signal capture with low-noise amplifiers. This means your home WiFi has improved range and full-signal strength for every device.
Gigabit Wired Speeds
Full Gigabit Ports for PCs, IPTVs, and Game Consoles
Equipped with full gigabit ports which are 10× faster than Ethernet ports, MR30G transfers data at dizzying speeds for peak performance. Connect your PCs, IPTVs, and game consoles to MR30G for robust stability.
Easily Manage Your Home Network
Parental Controls
Establish appropriate policies to protect children for responsible, safe internet access
Guest Network
Allows guests to join your WiFi network—all while protecting your privacy—making sharing easy and secure
Quality of Service
Prioritizes devices you select to perform better
Multi-Mode for Flexible Application Scenarios
Router Mode
Creates a wireless network for all your WiFi devices
Access Point Mode
Extends a wired network and makes it wireless
Simple Setup
No Need to Call for Help
Simply follow the step-by-step instructions on the intuitive webpage to get set up in minutes. No complicated configuration required.
| WAN connection |
|---|
| WAN connection type |
RJ-45 |
| 3G/4G USB modem compatibility |
No |
| SIM card slot |
No |
| DSL WAN |
No |
| Ethernet WAN |
Yes |
| Wireless LAN features |
|---|
| WLAN data transfer rate (second band) |
867 Mbit/s |
| WLAN data transfer rate (first band) |
300 Mbit/s |
| Wi-Fi standards |
802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
| WLAN data transfer rate (max) |
1167 Mbit/s |
| Top Wi-Fi standard |
Wi-Fi 5 (802.11ac) |
| Wi-Fi band |
Dual-band (2.4 GHz / 5 GHz) |
| Network |
|---|
| Receiver sensitivity |
11g 6Mbps: -96dBm11g 54Mbps: -78dBm11n HT40 MCS7: -74dBm11n HT20 MCS7: -71dBm11a 6Mbps: -97dBm11a 54Mbps: -79dBm11ac VHT20 MCS8: -74dBm11ac VHT40 MCS9: -70dBm11ac VHT80 MCS9: -65dBm |
| Cabling technology |
10/100/1000Base-T(X) |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| Ethernet LAN interface type |
Gigabit Ethernet |
| Ethernet LAN |
Yes |
| Mobile network |
|---|
| 5G |
No |
| 3G |
No |
| 4G |
No |
| Ports & interfaces |
|---|
| DC-in jack |
Yes |
| USB port |
No |
| Ethernet LAN (RJ-45) ports |
3 |
| Management features |
|---|
| MU-MIMO technology |
Yes |
| MIMO |
Yes |
| WPS push button |
Yes |
| Reset button |
Yes |
| Web-based management |
Yes |
| Security |
|---|
| NAT functionality |
Port Forwarding, Port Triggering, UPnP, DMZ |
| Network address translation (NAT) |
Yes |
| Parental control |
Yes |
| Firewall security |
SPI Firewall, IP/MAC Address Binding |
| Access Control List (ACL) |
Yes |
| Guest access |
Yes |
| Firewall |
Yes |
| Security algorithms |
WPA-PSK, WPA2-PSK |
| Protocols |
|---|
| Supported network protocols |
PPPoE/L2TP/PPTP |
| DHCP server |
Yes |
| DHCP client |
Yes |
| Design |
|---|
| LED indicators |
Status |
| Product colour |
Black |
| Product type |
Tabletop router |
| Packaging content |
|---|
| Quick installation guide |
Yes |
| Antenna included |
Yes |
| AC adapter included |
Yes |
| Cables included |
LAN (RJ-45) |
| Antenna |
|---|
| Antennas quantity |
4 |
| Antenna gain level (max) |
5 dBi |
| Antenna design |
External |
| Power |
|---|
| External power adapter |
Yes |
| Power source type |
AC |
| Operational conditions |
|---|
| Operating temperature (T-T) |
0 - 40 °C |
| Operating relative humidity (H-H) |
10 - 90% |
| Storage relative humidity (H-H) |
5 - 90% |
| Weight & dimensions |
|---|
| Width |
159.7 mm |
| Depth |
125.9 mm |
| Height |
37.1 mm |
| Packaging data |
|---|
| Package type |
Box |
