Superior Reading Performance
The BS80 Piranha II is offered in 2 versions, containing a 1D or a 1D+2D barcode scanning engine. Both of these engines read virtually any barcode from paper or screen. The 2D device has been equipped with a laser aimer with a red cross to make barcode reading easier and faster.
Easy Bluetooth Pairing
With Bluetooth 4.0 wireless technology, the BS80 Piranha II enables effortless pairing to any Android, iOS, or Windows device, making it simple and convenient for users to transmit data.
Seamless Barcode Capture and Storage
Offering versatile barcode scanning capabilities, the BS80 Piranha II enables fast real-time scanning with seamless data transfer to the host via Bluetooth. However, users can also take advantage of the 1MB memory when operating in batch collection mode, which can store thousands of barcodes offline for subsequent download via Bluetooth or cable.
Edits On the Go
The BS80 Piranha II boasts not only a reliable scan button but also two extra buttons for convenient data editing. For data collection mode, the Delete button allows users to quickly rectify scanning errors by deleting the last scanned barcode. Meanwhile, the Function button serves as a virtual keyboard recall feature, enabling manual data input on a wide range of host devices, including iOS products. This makes the BS80 Piranha II an ideal companion for all your data collection needs.
Versatile Charging & Communication
The BS80 Piranha II features a fast and reliable USB-C port that can be used both for charging and establishing a connection to a host to download data or access the EasySet configuration software. In addition, the device also supports the use of pogo pins to charge via the cradle.
Multi-Device Charging
The BS80 Piranha II offers an optional two-bay charging solution that can be easily linked together to create a multi-charging station. With optimized charging capabilities, users can daisy-chain up to five cradles, allowing them to charge up to ten scanners simultaneously using a single power supply.
| Scanning |
|---|
| Pitch reading angle |
-60 - 60° |
| Optical sensor resolution (W x H) |
1280 x 800 pixels |
| Sensor type |
CMOS |
| Linear (1D) barcodes supported |
China Post, Codabar, Code 128, Code 39, Code 93, EAN-13, EAN-8, GS1 DataBar, GS1-128 (UCC/EAN-128), ISBN, ISSN, Interleaved 2 of 5, MSI, PDF417, POSTNET, Plessey, UPC-A, UPC-E |
| 2D (matrix & stacked) barcodes supported |
Aztec Code, Data Matrix, MaxiCode, MicroPDF417, PDF417, QR Code |
| Scanner type |
1D/2D |
| Type |
Handheld bar code reader |
| Ports & interfaces |
|---|
| Operating frequency |
2400 - 2500 MHz |
| Bluetooth Low Energy (BLE) |
Yes |
| Bluetooth version |
4.0 |
| Wireless range |
50 m |
| Standard interfaces |
Bluetooth, USB |
| Connectivity technology |
Wired & Wireless |
| Performance |
|---|
| Certification |
TELEC, IEC 62471, IEC60825 |
| Programming function |
Yes |
| Vibration function |
Yes |
| Print contrast |
20% |
| Internal memory |
1 MB |
| Buzzer |
Yes |
| LED indicators |
Yes |
| Protection features |
Drop proof |
| International Protection (IP) code |
IP42 |
| Product colour |
Black, Orange |
| Power |
|---|
| Power consumption |
0.28 mA |
| Battery life |
5 h |
| Battery voltage |
3.7 V |
| Battery capacity |
900 mAh |
| Battery type |
Built-in battery |
| Battery technology |
Lithium-Ion (Li-Ion) |
| Power source type |
Battery |
| Weight & dimensions |
|---|
| Weight |
63 g |
| Height |
24.5 mm |
| Depth |
88 mm |
| Width |
46 mm |
| Operational conditions |
|---|
| Operating temperature (T-T) |
-20 - 50 °C |
| Storage temperature (T-T) |
-40 - 70 °C |
| Operating relative humidity (H-H) |
5 - 95% |
| Technical details |
|---|
| Sustainability compliance |
Yes |
| Compliance certificates |
CE, Federal Communications Commission (FCC), RoHS |
