Create a high-resolution 4k x 2k connection with HBR2 support between your Mini DisplayPort™-equipped laptop and a standard DP monitor
The MDP2DPMM10 10ft Mini DisplayPort™ to DisplayPort Adapter Cable, features a Mini DP male connector on one end, and a DP male connector on the other, allowing you to connect any Mini DisplayPort-equipped laptop (including the Mac® family of products) to an HDTV, monitor or projector that uses a standard DisplayPort connection.
The mDP to DP cable supports high resolutions of up to 4k x 2k (3840 x 2160) @ 60Hz with a maximum HBR2 bandwidth of 21.6 Gbps. The cable also supports Multi-Stream (MST) for daisy chaining multiple monitors and provides optional audio support.
The MDP2DPMM10 is backed by StarTech.com’s Lifetime Warranty, for guaranteed reliability and ensures that digitally protected content is displayed properly, with both HDCP and DPCP capability.
Please Note : Newer laptop and desktop computers (e.g. Apple®) come equipped with Thunderbolt™ ports only. Our Mini DP to DP Cables can be connected to the Thunderbolt ports, enabling you to connect your DP compatible displays.
The StarTech.com Advantage
| Features |
|---|
| Number of conductors |
19 |
| Multi-Stream Transport (MST) |
Yes |
| Plug and Play |
Yes |
| Bandwidth |
21600 MB/s |
| AWG wire size |
32 |
| Jacket material |
Polyvinyl chloride (PVC) |
| Cable shielding |
Aluminum mylar foil |
| Cable rating |
CMG (CM) |
| Product colour |
Black |
| DisplayPort Content Protection (DPCP) |
Yes |
| HDCP |
Yes |
| Maximum refresh rate |
120 Hz |
| Supported graphics resolutions |
3840 x 2400, 2560 x 1600 (WQXGA) |
| Maximum resolution |
3840 x 2160 pixels |
| DisplayPort version |
1.2 |
| Connector contacts plating |
Gold |
| Connector 2 form factor |
Straight |
| Connector 1 form factor |
Straight |
| Connector 2 gender |
Male |
| Connector 1 gender |
Male |
| Connector 2 |
DisplayPort |
| Connector 1 |
mini DisplayPort |
| Cable length |
3 m |
| Operational conditions |
|---|
| Operating relative humidity (H-H) |
10 - 85% |
| Storage temperature (T-T) |
-10 - 70 °C |
| Operating temperature (T-T) |
0 - 45 °C |
| Certificates |
|---|
| Compliance certificates |
RoHS, CE |
| Weight & dimensions |
|---|
| Weight |
103.9 g |
| Cable diameter |
4.8 mm |
| Packaging data |
|---|
| Package weight |
112.9 g |
| Package height |
22 mm |
| Package depth |
220 mm |
| Package width |
200 mm |
| Packaging content |
|---|
| Quantity per pack |
1 pc(s) |
| Logistics data |
|---|
| Products per master (outer) case |
50 pc(s) |
| Master (outer) case height |
215 mm |
| Master (outer) case length |
504 mm |
| Master (outer) case width |
332 mm |
| Harmonized System (HS) code |
84733080 |
