TP-Link LiteWave 10-Port Gigabit Desktop Switch with 8-Port PoE+

SKU: LS1210GP
£74.15 inc. VAT
  • Full Gigabit Ports: 9× gigabit auto-negotiation RJ45 Ethernet ports and 1× gigabit SFP port provide up to 20 Gbps switching capacity
  • 61 W PoE Budget: Eight gigabit 802.3af/at-compliant PoE+ ports easily connect and power fixed devices like IP cameras, access points, and IP phones via a single cable. Up to 30 W PoE output is supported by each PoE port.*
  • Up to 250 m PoE Transmission: With Extend Mode, PoE transmission distance reaches up to 250m, perfect for surveillance camera deployment in large areas.**
  • PoE Auto Recovery: Automatically reboots your dropped or unresponsive PoE-powered devices
  • Traffic Separation for Higher Security: Isolation Mode allows one-click client traffic separation to avoid snooping and tampering, and isolate broadcast storm
  • Plug and Play: Simply plug and play for instant connectivity with no configuration required
  • Silent Operation: Fanless design reduces power consumption and ensures silent operation, ideal for noise-sensitive homes or businesses
  • Reliable Hardware Design: Durable metal casing and desktop/wall-mounting design are well-suited for different environments

Overview
The TP-Link LiteWave Series PoE Switches require no configuration and provide PoE (Power over Ethernet) ports. They can automatically detect and supply power with all IEEE 802.3af/at compliant Powered Devices (PDs). In this situation, the electrical power is transmitted along with data in one single cable allowing you to expand your network to where there are no power lines or outlets, where you wish to fix devices such as APs, IP Cameras or IP Phones, etc.

Management features
Quality of Service (QoS) support Yes
Switch type Unmanaged
Ports & interfaces
SFP module slots quantity 1
Basic switching RJ-45 Ethernet ports type Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity 9
Network
Auto MDI/MDI-X Yes
Flow control support Yes
Auto-negotiation Yes
Cable types supported Cat3, Cat4, Cat5, Cat5e
10G support No
Networking standards IEEE 802.1p, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Data transmission
Jumbo frames 16000
Store-and-forward Yes
Forwarding rate 14.88 Mpps
Switching capacity 20 Gbit/s
MAC address table 4000 entries
Design
LED indicators Yes
Product colour Black
Power
Power consumption (max) 76.96 W
DC input voltage 53.5 V
AC input frequency 50 Hz
AC input voltage 220 V
Power supply included Yes
Power source DC/PoE
Power over Ethernet (PoE)
Total Power over Ethernet (PoE) budget 61 W
Power over Ethernet (PoE) power per port 30 W
Power over Ethernet (PoE) ports quantity 8
Power over Ethernet (PoE) Yes
Operational conditions
Heat dissipation 261.66 BTU/h
Storage relative humidity (H-H) 5 - 90%
Operating relative humidity (H-H) 10 - 90%
Storage temperature (T-T) -40 - 70 °C
Operating temperature (T-T) 0 - 40 °C
Weight & dimensions
Height 26 mm
Depth 126 mm
Width 209 mm
Packaging content
User guide Yes
Packaging data
Package type Box
General
Product family LiteWave
Certificates
Certification CE, FCC, RoHS
